1017SCG - Week 5

Foundation Mathematics

1017SCG

Week 5

Topics for Week 5

Solving Linear Equations
Solving Quadratic Equations
Solving Logarithmic Equations
Solving Exponential Equations

Solving Linear Equations

👉 $3x-7=9,\;\; 8y+2=9,\; 3n-1=-10$

Allowed: $\,x,\,$ constants ✅

Not allowed: $\,x^2,\,x^3,\, x^{1/2},\, \sin x,\, \log (x), \,3^x, \,$ ❌

Solving Linear Equations

Allowed: $\,x,\,$ constants ✅

Not allowed: $\,x^2,\,x^3,\, x^{1/2},\, \sin x,\, \log (x), \,3^x, \,$ ❌

This is a linear equation:

$3x+5 = 17$

$3x+5-5 = 17-5$

$3x = 12$

$\dfrac{3x}{3} = \dfrac{12}{3}$

$x = 4$

Solving Linear Equations

Example 1: Solve $\,7 n - 10 = 2n + 15$

$7n - 10 + 10$	$=$	$2n + 15 + 10$
$7n$	$=$	$2n + 25$
$7n - 2n$	$=$	$2n - 2n + 25$
$5n$	$=$	$25$
$\dfrac{5n}{5}$	$=$	$\dfrac{25}{5}$
$n$	$=$	$5$

Solving Linear Equations

Example 2: Solve $\,\dfrac{3 y +8}{2} = \dfrac{10y+1}{3}$

$\dfrac{3 y +8}{2}\times 2$	$=$	$ \dfrac{10y+1}{3} \times 2$
$3 y +8 $	$=$	$\dfrac{2(10y+1)}{3} $
$(3y+8)\times 3$	$=$	$\dfrac{2(10y+1)}{3} \times 3$
$3(3y+8)$	$=$	$2(10y+1)$
$9y+ 24$	$=$	$20 y + 2$

Solving Linear Equations

Example 2: Solve $\,\dfrac{3 y +8}{2} = \dfrac{10y+1}{3}$

$9y+ 24$	$=$	$20 y + 2$
$24-2$	$=$	$20y - 9y$
$22$	$=$	$11y$
$y$	$=$	$2$

Solving Quadratic Equations

$3x^2-7=9,\;\; y^2-y+1=0,\; n^2-4=-2$

Allowed: $\,x^2,\,x,\,$ constants ✅

Not allowed: $\,x^3,\,x^4,\, x^{1/2},\, \sin x,\, \log (x), \,3^x, \,$ etc. ❌

Solving Quadratic Equations

Example 1 (Factorising): Solve $\,x^2-6x = 0$

$x(x-6)$	$=$	$0$
$x=0$	or	$x -6=0$
		$x = 6$

Solving Quadratic Equations

Example 2 (Factorising): Solve $\,3x^2+6x = 0$

$3x(x+2)$	$=$	$ 0$
$3 x =0 $	or	$x+2 =0$
$x=0$	or	$x=-2$

Solving Quadratic Equations

Example 3 (Factorising): Solve $\,x^2 + 5 x +4 =0$

$(x+1)(x+4)$	$=$	$ 0$
$x+1 =0 $	or	$x+4 =0$
$x=-1$	or	$x=-4$

Solving Quadratic Equations

Example 4 (Factorising): Solve $\,2x^2 + 9 x +4 =0$

$(2x+1)(x+4)$	$=$	$ 0$
$2x+1 =0 $	or	$x+4 =0$
$2x=-1$	or	$x=-4$
$x=-\dfrac{1}{2}$

What if we cannot easily factorise?

Try this one for example:
$x^2+2x-2=0$

The Quadratic formula

If we have the quadratic equation \[ax^2+bx+c=0,\] then \[ x=\dfrac{-b\pm \sqrt{b^2-4ac}}{2a} \]

Note: Developed by Indian mathematician Brahmagupta (circa 6th century) and Śrīdhara (8th-9th century).

Derivation of the Quadratic formula 🤓

$ax^2+ bx+c $	$=$	$ 0$
$ax^2 + bx $	$=$	$ -c$
$4a$$ax^2 \,+$$\,4a$$bx $	$=$	$-$$\,4a$$c$
$4a^2x^2 + 4abx\, +$$\,b^2$	$=$	$ -4ac\,+$$\,b^2$
$\left(2ax+b\right)^2$	$=$	$ b^2-4ac$
$2ax+b$	$=$	$ \pm \sqrt{b^2-4ac}$
$2ax$	$=$	$ -b \pm \sqrt{b^2-4ac}$
$x$	$=$	$ \dfrac{-b \pm \sqrt{b^2-4ac}}{2a}$

The Quadratic formula

If $ax^2+bx+c=0,$ then \[ x=\dfrac{-b\pm \sqrt{b^2-4ac}}{2a} \]

The symbol $\pm$ means that we get two solutions:

$ x=\dfrac{-b+ \sqrt{b^2-4ac}}{2a},\;\;\; $ $ x=\dfrac{-b- \sqrt{b^2-4ac}}{2a} $

Solving Quadratic Equations

Example 5: Solve $\,2x^2 -3 x -4 =0$

👉 $\;a = 2,\;\;$ $b = -3,\;\;$ $c = -4$

$x=\dfrac{-b\pm \sqrt{b^2-4ac}}{2a}\qquad \qquad\;\;$

$x = \dfrac{-(-3)\pm \sqrt{(-3)^2-4(2)(-4)}}{2(2)}$

$x = \dfrac{3\pm \sqrt{41}}{4}\qquad \qquad\qquad \quad$

Solving Quadratic Equations

Example 6: Solve $\,x^2 -6 x +9 =0$

👉 $\;a = 1,\;\;$ $b = -6,\;\;$ $c = 9$

$x=\dfrac{-b\pm \sqrt{b^2-4ac}}{2a}\qquad \qquad $

$x = \dfrac{-(-6)\pm \sqrt{(-6)^2-4(1)(9)}}{2(1)}$

$x = \dfrac{6\pm \sqrt{0}}{2}$ $= \dfrac{6}{2}$ $= 3 \qquad\quad \;\;\;$

👉 Note that we have only one solution‼

Solving Quadratic Equations

Example 6: Solve $\,x^2 -6 x +9 =0$

👉 Note that we have only one solution‼

We can solve this equation also by factorising!

$(x-3)(x-3)=0$

Then $\, x - 3 = 0 \,$ or $\,x-3=0$

This is just one equation $\, x - 3 = 0 $

Therefore $\, x =3$

Solving Quadratic Equations

🤔 What is the best strategy to solve $ax^2+ bx +c =0$?

$x^2-2x-2=0$	$x^2-7x+12=0$
$x=\dfrac{-(-2)\pm \sqrt{(-2)^2-4(1)(-2)}}{2(1)}$	$(x-3)(x-4)=0$
$x=1\pm \sqrt{3}$	$x=3, \; x = 4$

Solving Quadratic Equations

Final remark: When solving a quadratic equation, there are 3 possibilities:

There are 2 solutions: $x^2-2x-2=0$
There is 1 solution: $x^2-6x+9=0$
There are NO solutions: $x^2+1=0$

Geometric interpretation

Consider the cartesian coordinate system

Geometric interpretation

• 2 solutions: The parabola intersects the $x$-axis 2 times

Geometric interpretation

• 1 solution: The parabola intersects the $x$-axis once

Geometric interpretation

• 0 solutions: The parabola does not intersect the $x$-axis

Solving Logarithmic Equations

$\log_{10}(100)\, $ $= 2\;$ because $\,10^2 = 100$

$\log_{2}(8)\, $ $= 3\;$ because $\,2^3 = 8$

Solving Logarithmic Equations

Example 1: Solve $\,\log_{2}(x)=4 $

$2^4$	$=$	$ x$
$16$	$=$	$x$
$x$	$=$	$ 16$

Solving Logarithmic Equations

Example 2: Solve $\,\log_{5}(2x)=3 $

$5^3$	$=$	$ 2x$
$125$	$=$	$2x$
$\dfrac{125}{2}$	$=$	$ \dfrac{2x}{2}$
$x$	$=$	$ \dfrac{125}{2}$

Solving Logarithmic Equations

Example 3: Solve $\,5\log_{2}(3x-1)=10 $

$\dfrac{5\log_{2}(3x-1)}{5}$	$=$	$ \dfrac{10}{5}$
$\log_{2}(3x-1)$	$=$	$2$
$2^2$	$=$	$3x-1$
$4$	$=$	$ 3x-1$

Solving Logarithmic Equations

Example 3: Solve $\,5\log_{2}(3x-1)=10 $

$4$	$=$	$ 3x-1$
$4+1$	$=$	$ 3x-1+1$
$5$	$=$	$ 3x$
$\dfrac{5}{3}$	$=$	$ \dfrac{3x}{3}$
$x$	$=$	$ \dfrac{5}{3}$

Solving Exponential Equations

Example 1: Solve $\,5^x=100 $

$\log_{10}\left(5^x\right) $	$=$	$ \log_{10}(100)$
$x\log_{10}\left(5\right)$	$=$	$\log_{10}(100)$
$x\log_{10}\left(5\right)$	$=$	$2$
$\dfrac{x\log_{10}\left(5\right)}{\log_{10}(5)}$	$=$	$ \dfrac{2}{\log_{10}(5)}$
$x$	$=$	$ \dfrac{2}{\log_{10}(5)}$ $\approx 2.86$

Solving Logarithmic Equations

Example 1: Solve $\,5^x=100 $

👉 log₁₀(5ˣ)= log₁₀(100)

$\;\log_{5}\left(5^x\right) $	$=$	$ \log_{5}(100)$
$x\log_{5}\left(5\right)$	$=$	$\log_{5}(100)$
$x$	$=$	$\log_{5}(100)$
$x$	$=$	$\dfrac{\log_{10}\left(100\right)}{\log_{10}(5)}$ $=\dfrac{2}{\log_{10}(5)}$ $\approx 2.86$

Solving Logarithmic Equations

Example 2: Solve $\,e^{2x}=10 $

$\ln\left(e^{2x}\right)$	$=$	$ 10$
$2x\ln\left(e\right)$	$=$	$\ln\left(10\right)$
$2x$	$=$	$\ln\left(10\right)$
$\dfrac{2x}{2}$	$=$	$ \dfrac{\ln\left(10\right)}{2}$
$x$	$=$	$\dfrac{\ln\left(10\right)}{2}$ $\approx 1.15$

Solving Logarithmic Equations

Example 3: Solve $\,7e^{3x}=28 $

$\dfrac{7e^{3x}}{7}$	$=$	$ \dfrac{28}{7}$
$e^{3x}$	$=$	$4$
$\ln\left(e^{3x}\right)$	$=$	$\ln(4)$
$3x\ln\left(e\right)$	$=$	$\ln\left(4\right)$
$3x$	$=$	$\ln\left(4\right)$

Solving Logarithmic Equations

Example 3: Solve $\,7e^{3x}=28 $

$3x$	$=$	$\ln\left(4\right)$
$\dfrac{3x}{3}$	$=$	$ \dfrac{\ln\left(4\right)}{3}$
$x$	$=$	$ \dfrac{\ln\left(4\right)}{3}$ $\approx 0.46$

Why do we need to know how
to solve equations anyway?

$2x-7=4,\;\; 2x^2-x+1=0,\;\; \log_3(2x) = 6,\;\; 4^x+2 = 3 $

📊 Linear Regression

Predicting height from age: Suppose we collect data from children aged 2 to 13 and record their heights.

📊 Linear Regression

Predicting height from age:

The data points suggest a linear trend:

\[ h(x) = m x + 70.36 \]

📈 Linear Regression

Predicting height from age:

The data points suggest a linear trend:

\[ h(x) = m x + 70.36 \]

$ x $: age in years
$ h(x) $: predicted height in cm
Slope $ m $: average growth per year

This line is the line of best fit — found using linear regression.

🚀 Motion of Objects/Particles Affected by Gravity

$y(x) = \ds \frac{g}{2u^2} x^2+\frac{v}{u}x$

☕️ Law of Cooling & 🧫 Population Growth


$T(t)=\left(T_0-T_m\right) e^{-kt} + T_m$	$\ds P(t) = \frac{\theta P_0 e^{rt}}{\theta-P_0+P_0e^{rt}}$

In summary

Solving equations teaches logical thinking and is a powerful tool for predicting, designing, optimizing, and understanding the world around us.

An example of modelling using functions

The beauty of mathematics shows itself to patient followers.

- Maryam Mirzakhani

$R =13 + 3\left(\dfrac{1}{2} + \dfrac{1}{2} \sin \left(2\pi t + \dfrac{z}{3}\right)\right)^4$

$y = z -\abs{x}\sqrt{ \dfrac{20 - \abs{x}}{35} }$

$x^{2}+y^{2}+z^{2}=R$
