Linear Algebra & Applications
2201NSC
Week 9 - Factorisations
Problem 1
- Prove that the inverse of a diagonal matrix must be diagonal matrix.
- Prove that the inverse of a lower-triangular matrix must be lower-triangular.
- Prove that the inverse of an upper-triangular matrix must be upper-triangular.
Problem 1 (cont.)
- Prove that the inverse of a diagonal matrix must be diagonal matrix.
Problem 2
Which of the factorisations we have considered (PLU, QR, Cholesky, SVD) has the following properties or requirements?
- Produces an orthogonal matrix?
- Produces an upper or lower triangular matrix?
- Can be applied to non-square matrices?
- Must be applied to real symmetric matrices?
- Provides an orthogonal basis for the column space?
Problem 3
Use software to calculate the PLU, QR, Cholesky and SVD factorisations for the following matrices, if possible. If not possible, indicate why the method cannot be applied.
| (a) $\,A=\begin{pmatrix} 0 & -1 \\ 1 & -1 \end{pmatrix}$ | (b) $\,A=\begin{pmatrix} 8 & 1 & 6 \\ 3 & 5 & 7\\ 4 & 9 & 2 \end{pmatrix}$ |
| (c) $\,A=\begin{pmatrix} 6 & 1 & -4 \\ 1 & 6 & -5 \\ -4 & -5 & 6 \end{pmatrix}$ | (d) $\,A=\begin{pmatrix} 4 & 0 & 0 \\ -1 & 4 & 1\\ 0 & 0 & 4 \end{pmatrix}$ |
| (e) $\,A=\begin{pmatrix} 3 & -1 \\ 1 & -1 \\ 2 & 3 \end{pmatrix}$ | (f) $\,A=\begin{pmatrix} 3 & -1 & 1 & 2 \\ 1 & -1 & 0 & -2 \\ 2 & 0 & 1 & 4 \end{pmatrix}$ |
Problem 3: Python code for part a)
PLU
import numpy as np
from scipy.linalg import lu, qr, svd, cholesky
A = np.array([[0, -1],
[1, -1]])
print("--- LDU decomposition ---")
P, L, U = lu(A) # SciPy: returns P, L, U
print("P:\n", P)
print("L:\n", L)
print("U:\n", U)
print("Check P*L*U:\n ", P @ L @ U)
👉 Run Python online here: tinket.io/python3
Note: The second line imports specific linear algebra routines form scipy.linalg. More details here: Linear algebra
Problem 3: Python code for part a)
QR
import numpy as np
from scipy.linalg import lu, qr, svd, cholesky
A = np.array([[0, -1],
[1, -1]])
print("\n--- QR decomposition ---")
Q, R = qr(A)
print("Q:\n", Q)
print("R:\n", R)
print("Check Q*R:\n", Q @ R)
Problem 3: Python code for part a)
Cholesky
import numpy as np
from scipy.linalg import lu, qr, svd, cholesky
A = np.array([[0, -1],
[1, -1]])
print("\n--- Cholesky decomposition ---")
try:
Rchol = cholesky(A, lower=False)
print("Rchol:\n", Rchol)
except Exception as e:
print("Cholesky failed:", e)
Note: The try/except statements check if it is possible to compute the Cholesky decomposition. More info here: Handling Exceptions
Problem 3: Python code for part a)
SVD
import numpy as np
from scipy.linalg import lu, qr, svd, cholesky
A = np.array([[0, -1],
[1, -1]])
print("\n--- SVD decomposition ---")
U_svd, S_svd, Vh_svd = svd(A)
print("U:\n", U_svd)
print("S (as diag):\n", np.diag(S_svd))
print("V^T:\n", Vh_svd)
print("Check U*S*V^T:\n", U_svd @ np.diag(S_svd) @ Vh_svd)
Remark 1: For part f) you may need to modify code.
Remark 2: For all cases, if you prefer to set a specific number of decimals, after the scipy routines are imported, include this line of code:
Problem 4
For any of the SVD factorisations calculated above, compare the SVD factorisation of $A$ with the matrices obtained from diagonalisation of $A^T A$ and $A A^T$.
Problem 4: Python code
import numpy as np
# Set NumPy printing precision
np.set_printoptions(precision=5, suppress=True)
# Define matrices
A = np.array([[0, -1],
[1, -1]])
# SVD
U, S, Vt = np.linalg.svd(A)
print("U =\n", U, "\n")
print("S (singular values) =", S, "\n")
print("V^T =\n", Vt, "\n")
# Eigenvalues of A A^T
eigvals_AAt, Ueig = np.linalg.eig(A @ A.T)
print("Eigenvalues of A A^T =", eigvals_AAt)
print("Real sqrt of eigenvalues =", np.sqrt(np.real(eigvals_AAt)), "\n")
# Eigenvalues of A^T A
eigvals_AtA, Veig = np.linalg.eig(A.T @ A)
print("Eigenvalues of A^T A =", eigvals_AtA)
print("Real sqrt of eigenvalues =", np.sqrt(np.real(eigvals_AtA)))
Problem 5
Solve the least-squares problem in 5.7.2, for the data provided in that section, using the QR factorisation approach. Solve for a fit to the following equations:
-
$y=a e^{-x} + b e^{-x/2} + c$
(see 5.7.2 for the solution using the direct method) - $y=ax^3 + bx^2 + cx + d$
Problem 5 (cont.)
- $y=a e^{-x} + b e^{-x/2} + c\;\;$ (see 5.7.2 for direct method)
Python code for part (b)
import numpy as np
from scipy.linalg import qr
import matplotlib.pyplot as plt
# Set NumPy printing precision
np.set_printoptions(precision=5, suppress=True)
# Data
x = np.array([1,2,3,4,5,6,7,8,9,10], dtype=float)
y = np.array([0.6,2.1837,2.8844,4.3985,4.2369,4.7755,5.5160,5.6721,5.6654,4.7268],dtype=float)
X_cubic = np.column_stack([x**3, x**2, x, np.ones_like(x)])
Q, R = qr(X_cubic, mode='economic')
R_inv = np.linalg.inv(R)
coef_cubic = R_inv @ Q.T @ y
print("Coefficients (a3, a2, a1, a0)^T = \n", coef_cubic)
Python code for part (b)
# Predictions
x_fit = np.linspace(1, 10, 200)
y_cubic_fit = coef_cubic[0]*x_fit**3 + coef_cubic[1]*x_fit**2 + coef_cubic[2]*x_fit + coef_cubic[3]
# ---- Plot ----
plt.figure(figsize=(8,6))
plt.scatter(x, y, color="black", label="Data", zorder=5)
plt.plot(x_fit, y_cubic_fit, "b--", label="Cubic fit")
plt.xlabel("x")
plt.ylabel("y")
plt.title("Least-Squares Approximations")
plt.legend()
plt.grid(True)
plt.show()
Python code for part (b)
import numpy as np
from scipy.linalg import qr
import matplotlib.pyplot as plt
# Set NumPy printing precision
np.set_printoptions(precision=5, suppress=True)
# Data
x = np.array([1,2,3,4,5,6,7,8,9,10], dtype=float)
y = np.array([0.6,2.1837,2.8844,4.3985,4.2369,4.7755,5.5160,5.6721,5.6654,4.7268], dtype=float)
X_cubic = np.column_stack([x**3, x**2, x, np.ones_like(x)]) # Create matrix
Q, R = qr(X_cubic, mode='economic') # mode='economic' reshapes Q and R
R_inv = np.linalg.inv(R)
coef_cubic = R_inv @ Q.T @ y
print("Coefficients (a3, a2, a1, a0)^T = \n", coef_cubic)
# Predictions
x_fit = np.linspace(1, 10, 200)
y_cubic_fit = coef_cubic[0]*x_fit**3 + coef_cubic[1]*x_fit**2 + coef_cubic[2]*x_fit + coef_cubic[3]
# ---- Plot ----
plt.figure(figsize=(8,6))
plt.scatter(x, y, color="black", label="Data", zorder=5)
plt.plot(x_fit, y_cubic_fit, "b--", label="Cubic fit")
plt.xlabel("x")
plt.ylabel("y")
plt.title("Least-Squares Approximations")
plt.legend()
plt.grid(True)
plt.show()
